Hikvision AcuSense 4MP Dome – 2.8mm Lens, 40m Hybrid-Light, 120dB WDR, Alarm & Audio I/O, 12VDC/PoE

The Hikvision 4MP AcuSense Dome Camera delivers high-resolution imaging with advanced smart features including human/vehicle classification, built-in strobe and audio alarms, and IP67-rated weather resistance. Supports 12VDC or PoE power.

Features

• Supports Hikvision Embedded Open Platform (HEOP) and third-party apps

• 1.5 TOPS computing power, 60 MB system memory, 400 MB smart RAM, 2 GB eMMC storage

• High-quality 4MP imaging

• Smart Hybrid Light for long-range illumination

• Clear imaging in strong backlight with 130dB WDR

• Efficient H.265+ compression

• Focus on human/vehicle classification via deep learning

• Built-in two-way audio for real-time security

• On-board storage up to 512 GB (SD card slot)

• Active strobe and audio alarm to deter intruders

• Audio and alarm interface available

• Water and dust resistant (IP67)

Specifications

Camera

• Image Sensor: 1/3" Progressive Scan CMOS

• Max Resolution: 2688 × 1520

• Min Illumination: 0.001 Lux (Color), 0 Lux with light

• Shutter Time: 1/3 s to 1/100,000 s

• Day/Night: IR cut filter

• Angle Adjustment: Pan 0–360°, Tilt 0–75°, Rotate 0–360°

Lens

• Type: Fixed 2.8 mm (optional 4 mm)

• FOV 2.8 mm: H 100.2°, V 54.7°, D 119.7°

• FOV 4 mm: H 81.1°, V 44.7°, D 94.6°

• Iris: Fixed, F1.0

• Depth of Field: 2.8 mm: 1.9 m–∞; 4 mm: 2.5 m–∞

DORI

• 2.8 mm: D 63 m, O 25 m, R 12 m, I 6 m

• 4 mm: D 78 m, O 31 m, R 15 m, I 7 m

Illuminator

• Type: IR, White Light

• Range: Up to 40 m

• Smart Light: Yes, 850 nm IR

Video

• Compression: H.265/H.264/H.264+/H.265+

• Streams: Main, Sub, Third, Fourth

• Bitrate: 32 Kbps–8 Mbps

• ROI: 5 fixed regions, target cropping supported

Audio & Alarm

• Audio: Mono, built-in microphone and speaker

• Audio/Alarm I/O: 1 input, 1 output (max 24 VDC/24 VAC, 1 A)

• Built-in speaker: Max 1.2 W, 10 cm: 95 dB

Network & Security

• Protocols: TCP/IP, HTTP/HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, UPnP, NTP, 802.1X, IPv4/IPv6

• Users: Up to 32, 3 levels (Admin, Operator, User)

• Security: Password, HTTPS, IP filter, watermark, TLS, MAC authentication

Storage

• microSD up to 512 GB

• NAS: NFS, SMB/CIFS, ANR

General

• Power: 12 VDC ±25%, max 10 W / PoE IEEE 802.3af, Class 3, max 12 W

• Material: Metal cover & body

• Dimensions: Ø138.3 × 115.4 mm

• Weight: 820 g / With package: 1316 g

• Operating Temp: -30°C to 60°C, Humidity ≤95%

Approvals

• EMC: CE-EMC, RCM, IC

• Safety: UL, CB, CE-LVD, BIS, LOA

• Environment: CE-RoHS

• Protection: IP67
