Pro Series 32-Channel POE NVR – 2 SATA, 10TB, Up to 8MP Recording, 1ch Facial Recognition / 4ch Face Capture, 16 POE Ports, 4/1 Alarm IO

Features

• Adopts Hikvision AcuSense technology to reduce manual effort and security costs

• Efficient playback with AcuSearch technology

• Accurate perimeter protection to effectively reduce false alarms

• Automatic camera connection and configuration

• Up to 32 IP camera inputs

• Supports H.265+/H.265/H.264+/H.264 video formats

• Decoding capacity: up to 3-ch @12 MP, 5-ch @8 MP, 10-ch @4 MP, or 20-ch @1080p

• Up to 256 Mbps incoming bandwidth

Specifications

Intelligent Analytics

• AI by NVR: Facial recognition, perimeter protection, motion detection 2.0, AcuSearch

• AI by Camera: Facial recognition, perimeter protection, motion detection 2.0, ANPR

• Facial Recognition: Face detection, face picture comparison, human face capture, face picture search

• Facial Detection Performance: Up to 4 MP: 2-ch; 5–8 MP: 1-ch

• Face Picture Comparison: 8-ch

• Face Picture Library: Up to 16 libraries, 50,000 face pictures total (≤1 MB per picture, total ≤1 GB)

• AcuSearch by Camera: All channels (camera must support AcuSearch)

• Motion Detection 2.0:

  • By NVR: All channels up to 4 MP (enhanced SVC mode up to 8 MP) for human/vehicle recognition

  • By Camera: All channels

• Perimeter Protection:

  • By NVR: Up to 4 MP: 2-ch; 5–8 MP: 1-ch, human/vehicle recognition

  • By Camera: All channels

Video & Audio

• IP Video Input: 32 channels

• IP Speaker Input: 4 channels

• Incoming Bandwidth: 256 Mbps

• Outgoing Bandwidth: 160 Mbps

• Video Output Mode: HDMI/VGA independent output

• HDMI Output: 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1080p and lower

• VGA Output: 1-ch, 1080p and lower

• Audio Output: 1-ch RCA (Linear, 1 KΩ)

• Two-Way Audio: 1-ch RCA (2.0 Vp-p, 1 KΩ)

Decoding

• Format: H.265/H.265+/H.264/H.264+

• Recording Resolution: 12 MP / 8 MP / 6 MP / 5 MP / 4 MP / 3 MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF

• Synchronous Playback: 16-ch

• Decoding Capability:

  • AI on: 16-ch @1080p (30 fps)

  • AI off: 20-ch @1080p (30 fps)

• Stream Type: Video, Video & Audio

• Audio Compression: G.711ulaw / G.711alaw / G.722 / G.726 / AAC / MP2L2

Network

• Remote Connections: 128

• API: ONVIF (Profile S/G), SDK, ISAPI

• Compatible Browsers: IE11, Chrome 91+, Firefox 88+, Safari 12+, Edge 91+

• Network Interfaces: 1 × RJ-45 10/100/1000 Mbps; 2 × RJ-45 10/100/1000 Mbps self-adaptive

• Network Protocols: TCP/IP, DHCP, IPv4/IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS

Auxiliary Interface

• SATA: 2 interfaces, up to 16 TB per HDD

• USB: Front 1 × USB 2.0, Rear 1 × USB 2.0

• Alarm In/Out: 4/1

General

• GUI Languages: English, Russian, Bulgarian, German, Italian, Spanish, French, Japanese, Korean, Chinese, Portuguese, and more

• Fan: Supports automatic speed control

• Power Supply: 12 VDC, 3.33 A

• Power Consumption: ≤ 15 W (without HDD)

• Operating Temperature: -10°C to +55°C (14°F to 131°F)

• Operating Humidity: 10% to 90%

• Dimensions (W×D×H): 384 × 317 × 52 mm (15.12 × 12.48 × 2.03 in)

• Weight: ≤ 1.8 kg (without HDD, 4.0 lb)

Certification

• CE, CB, REACH, WEEE, UKCA, RCM, IC

• EN55032: 2015, EN61000-3-2, EN61000-3-3, EN50130-4, EN55035:2017
