2MP PTZ Camera – 25× Optical Zoom, 100m IR, AcuSense VCA, 120dB WDR, 12VDC/PoE+

Features

• Focuses on human and vehicle targets using deep learning

• Supports face capture (up to 5 faces simultaneously)

• 1/2.8" progressive scan CMOS sensor with high-quality 2 MP imaging

• Excellent low-light performance with DarkFighter technology

• 25× optical zoom and 16× digital zoom for detailed close-ups

• Night view with up to 100 m IR distance

• Supports H.265+/H.265 video compression

Specifications

Camera

• Image Sensor: 1/2.8" progressive scan CMOS

• Max. Resolution: 1920 × 1080

• Min. Illumination: Color 0.005 Lux (F1.6, AGC ON), B/W 0.001 Lux (F1.6, AGC ON), 0 Lux with IR

• Shutter Speed: 1 s – 1/30,000 s

• Day & Night: IR cut filter

• Zoom: 25× optical, 16× digital

• Slow Shutter: Yes

Lens

• Focal Length: 4.8 mm – 120 mm

• FOV: Horizontal 57.6°–2.5°, Vertical 34.4°–1.4°, Diagonal 64.5°–2.9°

• Focus: Auto, semi-auto, manual

• Aperture: Max F1.6

• Zoom Speed: Approx. 3.6 s

Illuminator

• Supplement Light Type: IR

• Range: Up to 100 m

PTZ

• Pan Range: 360°

• Tilt Range: -15° to 90° (auto flip)

• Pan/Tilt Speed: Configurable 0.1°–80°/s, preset 80°/s

• Proportional Pan: Yes

• Presets: 300

• Patrol Scan: 8 patrols, up to 32 presets each

• Pattern Scan: 4 pattern scans

• Park Action: Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan

• 3D Positioning: Yes

• PTZ Status Display: Yes

• Scheduled Tasks: Preset/patrol/pattern scan, dome reboot/adjust, aux output

• Power-off Memory: Yes

Video

• Main Stream: 50 Hz – 25 fps, 60 Hz – 30 fps (1920 × 1080, 1280 × 960, 1280 × 720)

• Sub-Stream: 50 Hz – 25 fps, 60 Hz – 30 fps (704 × 576, 640 × 480, 352 × 288)

• Third Stream: 50 Hz – 25 fps, 60 Hz – 30 fps (multiple resolutions)

• Video Compression: H.265+/H.265/H.264+/H.264 (Main), H.265/H.264/MJPEG (Sub/Third)

• Bit Rate: 32 Kbps – 16,384 Kbps

• Scalable Video Coding: H.264/H.265

• Region of Interest: 8 fixed regions per stream

Audio

• Compression: G.711/G.722.1/G.726/MP2L2/PCM

• Bit Rate: 16–192 Kbps

• Sampling Rate: 8/16/32/48 kHz

• Environment Noise Filtering: Yes

Network & Security

• Protocols: IPv4/IPv6, HTTP/HTTPS, FTP, SMTP, RTSP/RTP, DHCP, DNS, NTP, UDP/TCP, IGMP, QoS, SNMP, UPnP, ICMP, DDNS, PPPoE, Bonjour

• Simultaneous Live View: Up to 20 channels

• API: ONVIF (Profile S/G/T), ISAPI, SDK, ISUP

• Users: Up to 32 users, 3 levels (admin/operator/user)

• Security: HTTPS, 802.1X, TLS 1.2/1.3, IP/MAC filtering, password protection, watermark, authentication controls

• Network Storage: NAS (NFS, SMB/CIFS), ANR support

• Client Software: iVMS-4200, HikCentral Pro, Hik-Connect

• Web Browser Support: Chrome 57+, Firefox 52+, Safari 11+, IE11


• Image Settings: Saturation, brightness, contrast, sharpness, gain, white balance adjustable

• Day/Night: Day/Night/Auto/Schedule

• WDR: 120 dB

• SNR: >52 dB

• Defog: Digital

• Enhancement: BLC, HLC, 3D DNR

• Privacy Mask: 24 programmable polygons

• Regional Focus/Exposure: Yes

Interface

• Ethernet: 1 RJ45 10/100 M

• On-board Storage: MicroSD/SDHC/SDXC up to 256 GB

• Audio: 1 input (line in), 1 output (line out)

• Alarm: 1 input, 1 output

• Reset: Yes

Event & Smart Functions

• Basic Event: Motion detection, video tampering, exception, alarm input/output

• Smart Event: Line crossing, intrusion, region entrance/exit, unattended baggage, object removal, audio exception

• Deep Learning: Face capture (up to 5), perimeter protection, alarm triggering for human/vehicle

• Linkage: Upload to FTP/NAS/memory card, notify center, trigger recording/alarm/PTZ actions

General

• Power: 12 VDC max 18 W (heater 1.6 W, IR 9 W), PoE (802.3at)

• Dimensions: Ø164.5 × 290 mm (6.48" × 11.42")

• Weight: Approx. 2 kg (4.41 lb.)

• Material: ADC12

• Operating Condition: -30 °C to 65 °C, ≤90% humidity

• Demist: Yes

Approval & Protection

• EMC/FCC/CE/RCM/IC/KC compliance

• Safety: UL, CB, CE-LVD, BIS, LOA

• Environment: CE-RoHS, WEEE, REACH

• Protection: IP66, TVS 6000V lightning, surge, voltage transient protection
