Hikvision AX Pro Wireless Alarm Panel – 96 Zones, 32 Partitions, LAN/WiFi/4G
The Hikvision AX Pro is a versatile wireless alarm panel with support for up to 96 zones and 32 partitions. Features Tri-X/Cam-X wireless protocol, AES-128 encrypted two-way communication, and multiple connectivity options including LAN, Wi-Fi, and 3/4G. Supports live video viewing, alarm notifications via app, email, or phone, and integrates with Hik-Connect & Hik-ProConnect.
Features
-
TCP/IP, Wi-Fi, and 3/4G connectivity
-
Tri-X/Cam-X wireless protocol with long-range transmission
-
AES-128 encrypted two-way communication
-
Supports up to 96 wireless zones (including 48 PIRCAMs), 48 keyfobs, 4 repeaters, 6 sounders, 8 tag readers/keypads
-
Up to 48 network users (1 installer, 1 admin, 46 users)
-
Voice prompts for user guidance
-
Configurable via Web client, mobile app, or Convergence Cloud
-
Push notifications, alarm video clips via app/email
-
4950 mAh backup battery for up to 12 hours operation
-
SIA-DC09 protocol, Contact ID, ARC support with Hik-IP Receiver/Receiver Pro
Specifications
Software & User Management
Hardware
-
RS232 output: Supported
-
Dual SIM slot
-
Tag reader built-in
-
Loudspeaker built-in
-
Wi-Fi standard: Supported
-
Zones: 96 (up to 48 PIRCAMs)
-
Keypads: 8 (including tag reader)
-
Wireless sounders: 6
-
Wireless repeaters: 4
-
Keyfobs: 48
-
Multi-transmitters: 6
Electrical & Wireless
-
Battery: 4950 mAh Li-ion, up to 12h operation
-
Power supply: Built-in
-
RF frequency: 868 MHz
-
Wireless security: Frequency hopping with AES-128 encryption
-
Operating temperature: -10 °C to +55 °C
General
-
Dimensions: 170 × 170 × 38.6 mm
-
Weight: 557.5 g
-
Material: Plastic, White
-
LED indicators: Arm/Disarm, Alarm, Tamper, Fault, Cloud, Power
Reporting & Protocols
-
SIA DC09 (SIA level 2, Contact ID), ISUP, ISAPI, OTAP
-
Hik-IP Receiver & Hik-IP Receiver Pro (Sur-Gard & Ademco 685)
-
Video verification & remote control supported
