Hybrid ColorVu 4MP Bullet Camera – 4 mm Lens, 60 m Hybrid IR/White Light, 130 dB WDR, 12VDC/PoE
Hikvision ColorVu technology provides 24/7 vivid colorful images with F1.0 advanced lenses, high performance sensors and
friendly lighting. F1.0 super-aperture collects more light to produce brighter images. Advanced sensor technology can vastly
improve the utilization of available light.
Features
-
4 MP high-quality imaging, 24/7 ColorVu colorful imaging
-
Smart Hybrid Light: long-range IR and White lights, 3 supplemental modes
-
130 dB scene-adaptive WDR for clear backlight imaging
-
Focus on human and vehicle classification via deep learning
-
Water and dust resistant (IP67), anti-corrosion design
-
Efficient H.265+ compression
Specifications
Camera & Lens
-
Image Sensor: 1/1.8" Progressive Scan CMOS
-
Max. Resolution: 2688 × 1520
-
Min. Illumination: 0.0005 Lux (color), 0 Lux with light
-
Lens: Fixed 4 mm, F1.0, M16 mount
-
Horizontal FOV: 89.2° | Vertical FOV: 45.5° | Diagonal FOV: 108.2°
-
Depth of Field: 3.1 m – ∞
-
DORI: D 75 m, O 30 m, R 15 m, I 7 m
Illuminator
-
Type: Hybrid IR/White Light, Smart Supplement Light
-
Range: Up to 60 m, IR wavelength 850 nm
Video & Image
-
Main Stream: 25/30 fps @ 2688×1520
-
Sub-stream: 25/30 fps @ 1280×720
-
Video Compression: H.265/H.264/H.265+/H.264+
-
Wide Dynamic Range (WDR): 130 dB
-
Image Enhancement: BLC, HLC, 3D DNR
-
Privacy Masks: 4 programmable
Audio & Network
-
Built-in arrayed dual-microphone
-
Simultaneous live view: up to 6 channels
-
ONVIF, ISAPI, SDK
-
Network storage: NAS (NFS, SMB/CIFS), ANR
General
-
Power: 12 VDC ±25% (max 8 W), PoE IEEE 802.3af Class 3 (max 9 W)
-
Dimensions: 286.7 × 93.3 × 91.2 mm
-
Weight: 1085 g (with package 1639 g)
-
Operating Temperature: -30 °C to 60 °C, Humidity ≤95%
-
Protection: IP67, NEMA 4X anti-corrosion
